BC REN-05 – REAR VIEW CAMERA FOR RENAULT TRAFIC, OPEL VIVARO and NISSAN PRIMASTAR VANS 2001-13

Rear view camera is built into the central brake light. This camera is compatible with MY 2001-2013 vans.

Technical parameters:

• CCD 1/3" scanning chip
• lens focal point: f: 2.8mm
• TV system: NTSC
• video output: 1.0V / 75Ohm
• sensing angle: 170°
• weather protection: IP69K
• camera connector: 4-pin screwdriver
• monitor connector: CINCH (RCA)
• cable length: 10m
• number of scanning pixels: 510x492
• horizontal resolution: 420 TV lines
• white balance: automatically
• minimum lighting: 0.5 LUX
• signal-to-noise ratio:> 48dB
• Electronic shutter: 1/60 to 1/100000 sec.
• power consumption: <3W
• supply voltage: 12V
• operating temperature from -30 °C to + 70 °C
• homologated: yes

1. base 141 x 55 mm - oval
2. embedded depth: 50mm
