High-resolution 17.8 cm (7'') Quad monitor, setup for up to four cameras or video signals. Of course, you can also connect a video signal of a DVD player or DVB-T receiver to entertain their passengers while driving. All four inputs can be either switched on the monitor by remote control or a 12 volt remote input .

SPECIFICATIONS

• 17.8cm (7'' ) Active Matrix Digital TFT LCD ( Color)
• View full image / 2 cameras / 3 cameras / 4 cameras (Full , Split, Quad)
• Each video input can be mirrored individually
• Screen display can be rotated through 180 °
• Screen Format 16:9
• Extremely high resolution of 3 x 480 x 234 dots
• LED backlight
• Brightness 250cd / m²
• Contrast 500:1
• Vertical Viewing Angle 120 °
• Horizontal viewing angle 140 °
• 4x video inputs (CVBS RCA) 1 Vp-p, 75 ohms
• 4x switch inputs for priority circuit of a video input ( 12 volts)
• Automatic NTSC / PAL switching
• Automatic start when the operating voltage
• IR remote control for operating settings
• Housing with low-reflection black rubber touch surface
• Self-adhesive mounting base included
• Operating voltage 12-24 Volt DC
• Power Consumption < 800mA ; <10 watts
• Operating Temperature -20 ° to 60 ° C
• Storage temperature -30 ° to 60 ° C
• Dimensions 170 x 114 x 40mm
• Weight 376g

WIRING

• RED : Ignition 12-24 Volt DC
• BLACK : ground
• BROWN Video input 1
• GREEN : Video input 2
• BLUE : Video Input 3
• WHITE : Video Input 4
